Metal 84 Inner Arc Ring

Metal 84 inner arc ring filler plays an important role in many fields such as chemical industry, environmental protection, petroleum, metallurgy and so on. Its unique structural design and material selection make it exhibit excellent performance in fluid handling processes

The special inner arc shape of the metal 84 inner arc ring packing can effectively guide the flow of the fluid, reduce the resistance and pressure drop of the fluid, thus improving the operating efficiency of the whole system. This design enables the packing to form a uniform fluid distribution in the tower or reactor, avoiding the phenomenon of short circuit and dead Angle of the fluid, and improving the efficiency of mass and heat transfer.

DN25 stainless steel eight-four inner arc ring packing metal eight-column ring, also known as Mailer ring packing, is characterized by a large open area of the ring wall, so it has the characteristics of large flux, small resistance and high mass transfer efficiency compared with the Pall ring, the flux can be increased by 15-30%, and the pressure drop can be reduced by 20-30%.

DN25 stainless steel eight four inner arc ring packing metal eight column ring also called Mailer ring packing also called VSP eight column ring packing VSP ring packing name is the origin of its English name: Foreign customers like to call VSP ring Packing, that is, we usually say eighty-four inner arc ring packing, its specifications include DN38 and DN50, two models

DN25 stainless steel eight four inner arc ring packing metal eight column ring is also called Mailer ring packing because most of the stainless steel 304, 321, 316 and other materials made of steel strip. Metal 84 inner arc ring according to the high temperature resistance, the use of pressure and corrosion resistance requirements are different, generally made of carbon steel, stainless steel material processing, so it is also called stainless steel 84 inner arc ring filler, the product is processed by stainless steel strip into a axial alternate arrangement of eight and four inner arc and named. DN25 metal 84 inner arc ring 25mm stainless steel Mailer ring packing is widely used in petrochemical, chemical fertilizer, chemical industry, environmental protection, pharmaceutical, sugar and other industries of packing tower. For example, it has been widely used in large-scale equipment such as desulfurization, decarbonization, transformation and atmospheric and vacuum pressure of synthetic ammonia, and has achieved good results. It can also be used in the project of synthetic ammonia desulfurization tower, and the mass transfer efficiency and treatment effect are very good, and there are many applications in the field market.
