Types of Ceramic Packings

Ceramic packing (porcelain ring) has excellent acid and heat resistance, and can resist the corrosion of various acids and bases in addition to fluorooxic acid. Ceramic packing can be used in chemical industry, metallurgy, acid production, gas, oxygen production, steel, pharmaceutical, fine chemical industry scrubber, cooling tower, recycling tower, desulfurization tower, drying tower, absorption tower and reactor lining. More than 40 kinds of porcelain rings, such as three Y rings, rasi rings, cross partition rings, Pall rings, moment saddle rings, heterosaddle rings, conjugated rings, flat rings, etc.

Ceramic packing includes ceramic scattered packing and ceramic regular packing. Ceramic scattered packing is also called ceramic ring packing, ceramic ring packing, ceramic saddle ring packing is a new type of packing on the basis of the torque saddle ring packing to improve, the smooth curved side of the torque saddle packing into a zigzag shape or grain raised side. In this way, the contact gap between the fillers is increased in the packing bed, so that it is more conducive to the flow and diffusion of gas and liquid in the packing layer, and the mass transfer efficiency is high.

The shape of ceramic heterocyclic ring packing is heterocyclic ring, which has a unique three-dimensional structure. Each packing unit is saddle-shaped or curved, and this design allows the packing to form a larger specific surface area in the tower, increasing the chance of gas-liquid contact. At the same time, the special-shaped structure can effectively prevent the nesting and caking of the packing, and ensure the uniformity and stability of the packing layer. The main material of ceramic heterosaddle ring packing is alumina ceramic. Alumina ceramics with high temperature stability, corrosion resistance and good mechanical strength, make ceramic different saddle ring filler in the performance of the poor working conditions remain stable.
